CAT4 CPE R016
1*100M RJ45; 5V Typec Power USB ;4* External Antenna Interface(2* LTE, 2* Wifi)
Detailed parameters
-
SIM：3FF SIM Slotx 1 +5*6 ESMx2
-
LED：Three colors can indicate the current working status
-
LAN：1*RJ45 10/100M
-
Battery：NA
-
Button：Restore/PS
-
Voice：NA
-
Dimensionst：225 x 133.6 x38.7 mm
-
Weight：TBD
-
Standard:802.11 b/g/n wifi 2x2
-
Frequency Range :2412~2484 MHz (CH 1-13)
-
Security:WEP 64,WEP128, WPA-PSK,WPA-PSK2
-
Temperature: Operating Temperature: 00C ~ 450C
-
Temperature: Storage Temperature: -200C ~ 650C
-
Humidity : 5% ~ 95%
-
External Antenna : LTE x2 (Non detachable), Wifi x2(Non detachable)
-
Rx Sensitivity : TDD-LTE Typical:-100 dBm(10MHZ)
-
Rx Sensitivity: FDD-LTE Typical:-100 dBm(10MHZ
-
Modulation : DL: QPSK / 16QAM / 64QAM
-
Modulation: UL: QPSK / 16QAM
-
Output Power : 23±2 dBm
-
Standard: 3GPP Release 9
-
Standard: UE Category 4
-
Standard: FDD-LTE: DL: 150 Mbps / UL: 50 Mbps
-
Standard: TD-LTE: DL: 112 Mbps / UL: 10 Mbps
